Rodzaj łożyska: Dwa łożyska kulkowe
Materiał: Impeller &Frame: Plastik (UL94V-0)
Przewody ołowiowe: UL1007community 355;AWG26
Red Wire dodatni (+)
Czarny przewód ujemny一)
Waga: 450.0g
| MODEL | Bearing System | Rated Voltage | Operating Voltage Range | Input Current | Speed | Maximum Air Flow | Maximum Air Pressure | Noise |
| PART NO | B/S/F | VDE | VDE | AMP | RPM | CFM | MmH2O | Db-A |
| WSA012038_12L | B | 12 | 7.0~13.2 | 1.2 | 4000 | 141.1 | 11.6 | 41 |
| WSA012038_12M | B | 12 | 7.0~13.2 | 2.0 | 5000 | 177.1 | 18.1 | 46 |
| WSA012038_12H | B | 12 | 7.0~13.2 | 3.3 | 6000 | 212.2 | 26.1 | 50 |
| WSA012038_24L | B | 24 | 14.0~26.4 | 0.9 | 4000 | 141.1 | 11.6 | 41 |
| WSA012038_24M | B | 24 | 14.0~26.4 | 1.8 | 5000 | 177.1 | 18.1 | 46 |
| WSA012038_24H | B | 24 | 14.0~26.4 | 2.8 | 6000 | 212.2 | 26.1 | 50 |
