Rodzaj łożyska: Dwa łożyska kulkowe
Materiał: Impeller &Frame: Plastik (UL94V-0)
Przewody ołowiowe: UL1007community 355;AWG26
Red Wire dodatni (+)
Czarny przewód ujemny一)
Waga: .0g
| MODEL | Bearing System | Rated Voltage | Operating Voltage Range | Input Current | Speed | Maximum Air Flow | Maximum Air Pressure | Noise |
| PART NO | B/S/F | VDE | VDE | AMP | RPM | CFM | MmH2O | Db-A |
| WSA09225_12J | B/S/F | 12 | 7.0~13.2 | 0.09 | 2100 | 39.2 | 0.09 | 25 |
| WSA09225_24J | B/S/F | 24 | 14.0~26.4 | 0.06 | 2100 | 39.2 | 0.09 | 25 |
| WSA09225_48J | B/S/F | 48 | 28.0~56.0 | 0.05 | 2100 | 39.2 | 0.09 | 25 |
| WSA09225_12L | B/S/F | 12 | 7.0~13.2 | 0.11 | 2450 | 44.8 | 0.11 | 30 |
| WSA09225_24L | B/S/F | 24 | 14.0~26.4 | 0.08 | 2450 | 44.8 | 0.11 | 30 |
| WSA09225_48L | B/S/F | 48 | 28.0~56.0 | 0.06 | 2450 | 44.8 | 0.11 | 30 |
| WSA09225_12M | B/S/F | 12 | 7.0~13.2 | 0.14 | 2850 | 52.1 | 0.16 | 34 |
| WSA09225_24M | B/S/F | 24 | 14.0~26.4 | 0.13 | 2850 | 52.1 | 0.16 | 34 |
| WSA09225_48M | B/S/F | 48 | 28.0~56.0 | 0.08 | 2850 | 52.1 | 0.16 | 34 |
| WSA09225_12H | B/S/F | 12 | 7.0~13.2 | 0.31 | 3200 | 58.3 | 0.18 | 38 |
| WSA09225_24H | B/S/F | 24 | 14.0~26.4 | 0.15 | 3200 | 58.3 | 0.18 | 38 |
| WSA09225_48H | B/S/F | 48 | 28.0~56.0 | 0.12 | 3200 | 58.3 | 0.18 | 38 |
| WSA09225_12U | B/S/F | 12 | 7.0~13.2 | 0.35 | 3800 | 69.2 | 0.26 | 45 |
| WSA09225_24U | B/S/F | 24 | 14.0~26.4 | 0.2 | 3800 | 69.2 | 0.26 | 45 |
| WSA09225_12V | B/S/F | 12 | 7.0~13.2 | 0.41 | 4200 | 69.2 | 0.4 | 49 |
