Rodzaj łożyska: Dwa łożyska kulkowe
Materiał: Impeller &Frame: Plastik (UL94V-0)
Przewody ołowiowe: UL1007community 355;AWG26
Red Wire dodatni (+)
Czarny przewód ujemny一)
Waga: 36.0g
| MODEL | Bearing System | Rated Voltage | Openrating Voltage Range | Input Current | Speed | Maximum Air Flow | Maximum Air Pressure | Noise |
| PART NO | B/S/F | VDE | VDE | AMP | RPM | CFM | MmH2O | Db-A |
| WSA07012_12L | B/S | 12 | 7.0~13.2 | 0.12 | 2000 | 3.68 | 3.42 | 25 |
| WSA07012_24L | B/S | 24 | 14.0~26.4 | 0.09 | 2000 | 3.68 | 3.42 | 25 |
| WSA07012_12M | B/S | 12 | 7.0~13.2 | 0.18 | 2500 | 4.6 | 4.28 | 28 |
| WSA07012_24M | B/S | 24 | 14.0~26.4 | 0.13 | 2500 | 4.6 | 4.28 | 28 |
| WSA07012_12H | B/S | 12 | 7.0~13.2 | 0. 30 | 3000 | 5.52 | 5.14 | 34 |
| WSA07012_24H | B/S | 24 | 14.0~26.4 | 0.2 | 3000 | 5.52 | 5.14 | 34 |
| WSA07012_12U | B/S | 12 | 7.0~13.2 | 0. 50 | 3800 | 6.99 | 6.15 | 43 |
| WSA07012_24U | B/S | 24 | 14.0~26.4 | 0.25 | 3800 | 6.99 | 6.15 | 43 |
| WSA07012_12V | B/S | 12 | 7.0~13.2 | 0. 65 | 4400 | 8.1 | 7.99 | 49.8 |
| WSA07012_24U | B/S | 24 | 14.0~26.4 | 0.35 | 4400 | 8.1 | 7.99 | 49.8 |
